Dual Reel Automatic Cable Take Up Machine

Wuxi Hengtai Cable Machinery Manufacture Co., Ltd
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap Dual Reel Automatic Cable Take Up Machine from wholesalers

    Buy cheap Dual Reel Automatic Cable Take Up Machine from wholesalers
    • Buy cheap Dual Reel Automatic Cable Take Up Machine from wholesalers

    Dual Reel Automatic Cable Take Up Machine

    Ask Lasest Price
    Brand Name : HNT
    Certification : ISO9001:2008, CE, High-tech enterprise
    Price : negotiable
    Delivery Time : 30-120 days
    Payment Terms : T/T, L/C
    • Product Details
    • Company Profile

    Dual Reel Automatic Cable Take Up Machine

    Dual Reel Take-up


    Description:

    1. The Takeup can work with extrusion line, coiling and packing machine, rewinding machine, ect...
    2. Structure: The pintle table is fixed, can not be moved from left and right;
    3. Bobbin shaft lifting mode: electric lifting;
    4. Pintle Clamp type: Cylinder;
    5. Wire Takeup power: AC motor + frequency converter + reducer;
    6. Wire takeup speed control: automatically control the motor wire feeding speed;
    7. Brake: pneumatic brake;
    8. Control system with PLC + HMI for the speed detection so that the whole system work with the line speed in synchronization.

    - Double reel Take-up Specification:

    ModelInner diameter (mm)Outer diameter (mm)Max load (kg)
    PF-1000M630 - 1000300 - 7501500
    PF-1250M800 - 1250450 - 9502500
    PF-1600M1000 - 1600600 - 12004000

    Dual Reel Automatic Cable Take Up Machine
