Cable Coil Wrapping Machine :

Machine Main Feature:

1. Connect with the extrusion line for the non-stop cable coiling and wrapping operation.

2. Machine with Auto holding arm adjust system after finished coiling.

3. With Auto labeling machine, saving labor cost,safe and convenience.

4. Can connect with robot stacking system.

5. System with automatic detection function, when problem come out, the machine can auto detect the mistakes, and send message to warn the operator.

6. Operation control Method:Touch screen+PLC；

7. Machine design Line speed:Max300M/min;

8. Microcomputer memory can store 99 different specifications of wire coil. When you need to change the product

specifications, you just need to read the data of the stored specifications. No need to input again, and you can produce immediately.

9. Over-gauge unit: The measuring unit is 0.01M, The measuring unit is 0.01M, forecast automatic deceleration, and the will automatic coiling with set meter.

10. Traverse device: by adopts Mitsubishi servo motor and synchronizes with the main machine of coiling.

11. Whole machine electrical circuit control: Mitsubishi microcomputer programmable controller (PLC).

12. Instrument and switch on the operation panel: touch screen, speed adjustment button.

13. Speed can be adjusted on the touch screen or the speed adjustment button.

14. The machine PLC has the power frequency sparker contact(the power frequency spark machine is provided by the customer)

15. Used for wire spark detection, automatic spark breakdown point or after manual marking can be continued coiling function.

16. If the diameter is not up to the requirement, the waste wire can be automatically eliminated or the coiling function can be continued after manual marking.

Technical Parameter:

Hengtai builds corporate brand and core competitiveness with "non-standard mechanical design, R&D and manufacturing capabilities", and can provide customized cable machinery and equipment according to customer needs. The main products include wire and cable extrusion production lines, stranding production lines, coiling and packaging production lines, take-ups and pay-offs and other related auxiliary equipments. The application range covers power cables, construction cables, solar PV cables, THHN cables, elevator flat cables, data cables, electronic cables, automotive cables and etc.

"Technical innovation" is the creed that Hengtai constantly adheres to. Hengtai never suspends R&D and innovation, and makes improvements and breakthroughs on the basis of traditional cable machinery, such as fully automatic coiling, strapping and packaging machine with robot arms, pallet conveyor line, intelligent warehousing and logistics workshop, etc. Hengtai is a nationally certified 'High Technology Expertise', and has passed ISO-9001 quality management system certification and CE certification.

"Manufacturing satisfactory equipment for customers and providing first-class service" is the basic tenet of Hengtai. With excellent performance, stable quality and thoughtful service, Hengtai has established close cooperative relations with customers from China, Germany，Switzerland，Portugal，Turkey，Romania，Japan，Middle East，Brazil，Malaysia，Thailand，Vietnam， India，indonesia and other countries and regions, and our customers from all over the world and at the same time get highly recognized and praised by customers.

In the future, Hengtai will adhere to the concept of "people-oriented, quality-based, customer-first, excellence-pursuing", keep digging into the wire and cable intelligent manufacturing industry, focus on creating value for customers, help customers achieve intelligent and digital transformation, and become the world's leading wire and cable Intelligent manufacturing solution provider.
