    Cantilever Motorized Wire Payoff Machine Cable Payoff

    Ask Lasest Price
    Brand Name : HNT
    Certification : ISO9001:2008, CE, High-tech enterprise
    Price : negotiable
    Delivery Time : 30-120 days
    Payment Terms : T/T, L/C
    • Product Details
    • Company Profile

    Cantilever Motorized Wire Payoff Machine Cable Payoff

    Cantilever Payoff


    Description:

    1. The pay-off can work with drawing machine, annealing machine, extrusion line, coiling and packing machine, rewinding machine, ect...

    2. Machine can be designed to Double reel payoff and Single Reel Payoff;

    3. Structure: The pintle table is fixed, can not be moved from left and right;

    4. Wire shaft lifting mode: electric lifting;

    5. Pintle Clamp type: Cylinder;

    6. Wire feeding power: AC motor + frequency converter + reducer;

    7. Wire feeding speed control: automatically control the motor wire feeding speed;

    8. Brake: pneumatic brake;

    9. Main electrical configuration, frequency converter. Contactor, intermediate relay, transformer. The switch. The electric motor. Speed reducer, etc;

    10. Control system with PLC + HMI for the speed detection so that the whole system work with the line speed in synchronization.


    - Double reel Pay-off Specification:

    ModelInner diameter (mm)Outer diameter (mm)Max load (kg)
    PF-1000M630 - 1000300 - 7501500
    PF-1250M800 - 1250450 - 9502500
    PF-1600M1000 - 1600600 - 12004000

    -Single Reel Pay-off Specification:

    ModelInner diameter (mm)Outer diameter (mm)Max load (kg)
    PFS-630M400 - 630300 - 475600
    PFS-800M630 - 800475 - 6001000
    PFS-1000M800 - 1000600 - 7501500
    PFS-1250M1000 - 1250750 - 9502500
