    Rigid Frame Strander for ACSR, AACSR, AAC, AAAC, ACAR, ACSS, ACCC Conductors

    Ask Lasest Price
    Brand Name : HNT
    Model Number : 630
    Certification : CE
    Payment Terms : L/C, T/T
    Delivery Time : 120days
    • Product Details
    • Company Profile

    Rigid Frame Strander for ACSR, AACSR, AAC, AAAC, ACAR, ACSS, ACCC Conductors

    Rigid Frame Strander for ACSR, AACSR, AAC, AAAC, ACAR, ACSS, ACCC Conductors

    Application:

    • Strand aluminum and copper wires to round, compressed. compact bare conductors;
    • Produce overhead power transmission cables;
    • Strand Milliken Conductors (Segmented Conductors);
    • Screen power cables with copper wires;
    • Strand insulated conductors;
    • Strander for ACSR, AACSR, AAC, AAAC, ACAR, ACSS, ACCC Conductors

    Rigid stranding lines for single copper or single aluminum wires, making compacting/non-compacting, round/sector, and straight/pre-spiral conductors.


    Main technical parameter:

    CategoryEquipmentQuantity
    PayoffsPND1600 pay-off device (column - type)1 set
    PND630 pay-off device (end cone - type)1 set
    Stranding Cage Model6 Bobbin Cage1 set
    12 Bobbin Cage1 set
    18 Bobbin Cage1 set
    24 Bobbin Cage1 set
    30 Bobbin Cage1 set
    Loading & Unloading SystemAutomatic side(or side - bottom) loading & unloading system5 sets ( 1 set for each cage)
    Auxiliary EquipmentClose die & compact head5 sets ( 1 die and 2 compact heads for each cage)
    Meter counter1 set
    CapstanDual capstan Φ25001 set
    Take - upsPN 1600 - 3150 portal-type take - up device with traversing1 set
    Safety SystemSafety cover1 set
    Controlling SystemHNT synchronous electrical control system1 set
    Single Wire DiameterMaximum Conductor SectionLine SpeedMaximum Rotating Speed (Empty / Full)

    Cu ø 1.5 - ø 4.5 mm
    Al ø 1.8 - ø 5.0 mm

    Round compact Cu 800 mm2
    Round compact Al 1200 mm2
    Sector Cu 630 mm2
    Pre - spiraled Cu 800 mm2
    Sector Al 800 mm2

    6 - 60
    m/min

    6 Bobbins 220/210 rpm
    12 Bobbins 220/190 rpm
    18 Bobbins 205/180 rpm
    24 Bobbins 205/150 rpm
    30 Bobbins 205/120 rpm

    Stranding PitchPre - spiral Rotating Lay LengthLine Center HeightPay - off Bobbin in Cage
    34 - 1024 mm800 - 2000 mm1100 mm

    PND630
    (Buyer provides the bobbin drawing
